FEATURES
Ball screws and servo motors adopted on X Y Z 3-axis for easy and precise feeds
Infinitely variable vertical cutting head with a swivel ±90°and the spindle controlled by variable frequency motor.
MPG adopted on X Y Z 3-axis ,easy operating
Specification | Unit | X8132 | X8140 | X8145 | |
Work space dimensions | mm | 750*320 | 800*400 | 850*450 | |
Vertical table dimensions | mm | 890*225 | 1020*225 | 1190*250 | |
T-slots,work table | mm | (5)14*63 | (6)14*63 | (7)14*63 | |
T-slots,vertical table | mm | (3)14*63 | (3)14*63 | (3)14*63 | |
Table load capacity | kg | 160 | 200 | 300 | |
travels | Longitudinal(X) | mm | 405 | 500 | 600 |
Transverse(Y) | mm | 305 | 400 | 450 | |
Vertical(Z) | mm | 400 | 400 | 450 | |
Speed range | rpm | (2)40-2000 | (2)40-2000 | (2)40-2000 | |
Spindle mount | NT40 | NT40 | NT40 | ||
Feeds X Y Z axis | mm/min | 10-1000 | 10-1000 | 10-1000 | |
Rapid feed | mm/min | 1200 | 1200 | 1200 | |
Quill stroke | mm | 60 | 60 | 60 | |
Main motor rating | kw | 3.7 | 3.7 | 5.5 | |
Feed motor rating | n.m | X：7.7 Y：7.7 Z：10 | X：7.7 Y：7.7 Z：10 | X：10 Y：10 Z：15 | |
Dimensions (L*W*H) | mm | 1500*1700*1800 | 1500*1700*1800 | 1600*1800*2000 | |
weight | kg | 1450 | 1550 | 1750 | |
The above milling machines can be equipped with CNC controller.
Standard accessories
Automatic oil lubrication |
Electronic handwheel |
Milling Arbors |
Reducing sleeves |
Collet chuck with collets |
Draw bar |
Coolant system |
Chip collector tray |
